Metal Drawer Box Set with Rails & Clips
Key Features
- Complete set: box + rails + clips
- 250–600 mm lengths, H 60/120/180 mm
- Galvanized steel, epoxy coated
- Load up to 50 kg
- Saves assembly time on production lines
- Packed 5 sets per carton
Product Overview
A complete metal drawer box set for kitchen and furniture production: galvanized steel box with an epoxy-coated finish, supplied with matching runners and clips so drawers arrive ready to assemble. Side heights of 60/120/180 mm combine freely with lengths from 250 to 600 mm, carrying up to 50 kg. Send drawer front widths and the mix of heights you need for a matched quotation.
Specifications
| Sizes | 250–600 mm (H: 60/120/180 mm) |
| Material | steel, galvanized |
| Finish | epoxy coated |
| Accessories | rails & clips included |
| Load | up to 50 kg |
| Packing | 5 sets/carton |
Applications
Available Options
- Heights: 60 / 120 / 180 mm
- Lengths 250–600 mm
- Mixed height combinations in one order
- Bulk packing: 5 sets per carton
Compatibility & Installation
The box assembles with the supplied clips; runners mount to the cabinet base or sides according to the drawer system. Confirm cabinet opening and drawer front size before ordering.
OEM / ODM
Sizes, finishes, hole patterns and packaging can be customized under your own brand. Send drawings, samples or a target specification for a quotation — see how OEM works.
FAQ
Do the rails come with the box?
+
Yes — rails and clips are included as a set; they can also be supplied separately.
Can I mix heights?
+
Yes — 60/120/180 mm sides combine freely with the same runners.
What is the load?
+
Up to 50 kg per drawer depending on runner configuration.
Packing?
+
5 sets per carton as standard.
